IP вызывная панель E12S

Physical & Power Specifications

Category: Details

Body Material: Plastic

Camera: 2M pixels, automatic lighting

Button: 1 call button with backlight

Wiegand port: Support

RF card reader: 13.56MHz

Light sensor: 1

Relays out: 1

Inputs: 2

Micro SD card slot: 1

Microphone: 1

Speaker: 1

Ethernet port: RJ45, 10/100Mbps adaptive

BLE: Yes

WiFi: IEEE802.11b/g/n, 2.4GHz (E12W Only)

Vandal alarm: Yes

802.3af Power-over-Ethernet: Yes

12V DC connector: (if not using PoE)

Power: 12V / 1A

Water-proof & Dust-proof: IP65

Installation: Wall-mounted

Size: 146x70x23mm

Working Humidity: 10~90%

Working Temperature: -40°C ~ +60°C

Storage Temperature: -40°C ~ +70°C

Audio Specifications

Category: Details

SIP: v1 (RFC2543), v2 (RFC3261)

Narrowband audio codec: G.711a, G.711μ

Wideband audio codec: G.722

DTMF: In-band, out-of-band DTMF (RFC2833), SIP Info

Echo Cancellation: Yes

Voice Activation Detection: Yes

Comfort Noise Generator

Yes

Video Specifications

Category: Details

Sensor: 1/2.7”, CMOS

Pixels: CIF, QCIF, VGA, 4CIF, 720p, 1080p

Video codec: H.264

Video resolution: up to 1920x1080

Max. image transfer rate: 1080p – 25fps

Viewing angle: 123°(H) / 69°(V)

White LEDs: for picture lighting during dark hours with internal light sensor

Door Entry Feature

Relays controlled: individually by DTMF tones

Camera: permanently operational

Auto-night mode: with LED illumination

White balance: auto

Minimum illumination: 0.1LUX

Networking & Protocol

Category: Details

Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

Deployment & Maintenance

Category: Details

Auto-Provisioning: Yes

Web management portal: Yes

Configuration backup / restore: Yes

Entry log export: Yes

Access table export / import: Yes

Firmware upgrade: Yes

System logs: (include door access logs)

Application Scenario

Category: Details

Apartment/flat intercom with door access control: Yes

Remote site entry over Internet: Yes
