Корпусная IP-камера IPC542E-DLC-C

IPC542E-DLC-C

Camera

Sensor: 1/2.8", 2.0 megapixel, progressive scan, CMOS

Shutter: Auto/Manual, 1 ~ 1/100000s

Minimum Illumination

Colour: 0.0005Lux (F1.2, AGC ON)

B/W: 0.0001Lux(F1.2, AGC ON)

Lens Mount: C/CS

Iris: DC-Iris/P-Iris, DC 5V (4 Pins)

Day/Night: IR-cut filter with auto switch (ICR)

Digital noise reduction: 2D/3D DNR

S/N: >52dB

Defog: Digital Defog

WDR: 120dB

Video

Video Compression: Ultra 265, H.264, MJPEG

H.264 code profile: Baseline profile, Main Profile, High Profile

Frame Rate

Main Stream: 2MP (1920*1080), Max 30fps;

Sub Stream: 2MP (1920*1080), Max 30fps;

Third Stream: D1 (720*576), Max 30fps

9:16 Corridor Mode: Supported

HLC: Supported

BLC: Supported

OSD: Up to 8 OSDs

Privacy Mask: Up to 8 areas

ROI: Up to 8 areas

Motion Detection: Up to 4 areas

Smart

General Function: Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Audio

Audio Compression: G.711

Two-way audio: Supported

Suppression: Supported

Sampling Rate: 8KHZ

Storage

Edge Storage: Micro SD, up to 256GB

Network Storage: ANR

Network

Protocols: IPv4, IGMP,ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS

Compatible Integration: ONVIF (Profile S, Profile G), API

Interface

Audio I/O: 3.5mm audio interface

Input: impedance 35k , amplitude 2V [p-p]

Output: impedance 600 , amplitude 2V [p-p]

Alarm I/O: 2/1

Zoom/focus: N/A

Serial Port: 1 RS485 (support Pelco-D/P)

Network: 1 RJ45 10M/100M Base-TX Ethernet

Video Output: 1 BNC, impedance 75 , amplitude 1V [p-p]

General

Power: AC 24V 10%, DC 12V 10%, PoE (IEEE 802.3af)

Power consumption: Max 6.8W

Dimensions (L W H): 151.5 x 71 x 65mm (6.0 x 2.8 x 2.6 ) (excluding the lens)

Weight: 0.48kg (1.1lb)

Working Environment: -20°C ~ 60°C (-4°F ~ 140°F), Humidity: 95% RH (non-condensing)

Reset Button: Supported
